PU heat transfer label reflective
PU heat transfer label is composed of retro reflective glass microspheres bonded to various thermosensitive.
The texture of the carved film is special, and this product needs to be used in conjunction with a computer engraving machine and a hot stamping machine, which is very convenient.
Product structure
*First layer is a PET protective layer
*Second layer is a glass bead layer
* Third layer is a reflective layer
* Fourth layer is polyester hot melt adhesive layer
*Fifth layer is backing film layer.
Typical property
| Material | TPU |
| Thickness | 0.13mm/0.16mm (excluding the thickness of the protective film) |
| Size | 5cm *100m or customized |
| Reflection | >400CPL |
| Attachment Type | Heat Transfer |
| Hot Press Temperature | 125-135℃ |
| Hot Press Time | 8-15s |
| Hot Press Pressure | 2-3kg/cm² |
| Washing Performance | 25 cycles@40℃ ISO6330 or Dry cleaning 10 cycles ISO3175 |
Features
1. Size pattern: Whether it's a large image or a small, hair like image, it's versatile and easy to transfer.
2. PET non stick fabric: Whether it is mesh fabric or fleece fabric, it is completely non stick.
3. High reflection with neat edges.
Application
